Hose tube containers for silo vehicles
ROWEKO hose tube containers reliably protect your hoses from dirt and damage. They fulfil the requirements for silo trailer forwarders as stipulated by the food and chemical industries.
Manufactured from high quality polyethylene and assembled with rust-resistant mounting parts, the hose tube containers are available in a diverse range of designs. In addition, doors can be mounted on both sides, so that the hoses can be easily removed at narrow loading points. The cleanliness of the couplings can also be monitored more easily, without the hose having to be fully removed from the container. It is also easier to handle 2 short hoses.
Hose tube containers for silo vehicles (PDF)General catalogue (PDF)
Types
The hose tube containers are available in designs for single, double and triple hose tubes. The length stated always refers to the hose length. The door and end cap make the total length approx. 40 mm longer. In the standard version, a door with flange is riveted to one side of the tube (riveted from inside to outside), and an end cap to the other side. On request, doors can be fitted to both sides.
Standard lengths up to 10 m ex stock. Excess lengths on request. Customised designs are naturally also possible.



Hose tube container, single
Length (m) | Diameter (mm) | Weight (kg / m) |
2,4 / 5,0 / 6,0 / 7,0 | 125 x 3,1 | 1,23 |
2,4 / 3,0 / 5,0 / 6,0 / 7,0 / 8,0 / 10,0 | 160 x 3,9 | 1,95 |
2,4 / 3,0 / 5,0 / 6,0 / 7,0 / 10,0 | 180 x 4,4 | 2,48 |
2,4 / 3,0 / 5,0 / 6,0 / 7,0 / 8,0 / 10,0 | 200 x 4,9 | 3,05 |
Execution
End piece and flange are fastened with 4 ea. VA rivets to the tube. The flange is riveted from inside to outside (exception: 125 mm). The cover is riveted with a VA hinge to the flange. The cover is locked as standard with a double-bit security rotary bolt. The locking latch grasps behind the aluminum locking bracket.
Scope of delivery
Tube complete with mounted/riveted lid (cover with flange) and end-fitting.
1 two-way key.
Accessories / Options
– Tube support
– Other locking systems (Spare parts)
– Door with flange on both sides
– Intermediate lengths are possible for all models (4% surcharge)

Hose tube container, double
Length (m) | Diameter (mm) | Weight (kg / m) |
2,4 / 3,0 / 5,0 / 6,0 / 7,0 / 8,0 / 10,0 | 160 x 3,9 | 3,90 |
2,4 / 3,0 / 5,0 / 6,0 / 7,0 / 10,0 | 180 x 4,4 | 4,96 |
2,4 / 3,0 / 5,0 / 6,0 / 7,0 / 8,0 / 10,0 | 200 x 4,9 | 6,10 |
2,4 / 5,0 / 6,0 / 7,0 | 250 x 6,2 | 9,66 |
Execution
End piece and flange are each attached to the tube container with 8 VA rivets. The flange is riveted from inside to outside. The cover is riveted with two VA hinges to the flange. The cover is locked as standard with a double-bit security rotary bolt (for Ø 250 mm with two security rotary bolts). The locking latch grasps behind the aluminum locking bracket.
Scope of delivery
Tube complete with assembled/riveted lid (cover with flange) and end-fitting.
1 two-way key (for Ø 250 mm with 2 keys).
Accessories / Options
– Tube support
– Other locking systems (Spare parts)
– Door with flange on both sides
– Intermediate lengths are possible for all models (4% surcharge)

Hose tube container, combination, double
Hinge on the left, right or bottom.
Lenght (m) | Weight (kg / m) |
2,4 / 3,0 / 5,0 / 6,0 / 7,0 / 8,0 / 10,0 | 5,00 |
Execution
A-Ø of bottom tube: 200 x 4,9 mm
A-Ø of top tube: 160 x 3,9 mm
End piece and flange are each attached to the tube container with 8 VA rivets. The flange is riveted from inside to outside. The cover is riveted with a VA hinge to the flange. The cover is locked standard with a double-bit security rotary bolt. The locking latches grasp behind the aluminum locking bracket.
Scope of delivery
Tube complete with assembled/riveted lid (cover with flange) and end-fitting, buffer tank, 1 two-way key.
Accessories / Options
– Tube support
– Other locking sytsems (Spare parts)
– Door with flange on both sides
– Intermediate lengths are possible for all models (4% surcharge)

Hose tube container, triple
Lenght (m) | Diameter (mm) | Weight (kg / m) |
2,4 / 3,0 / 5,0 / 6,0 / 7,0 / 8,0 / 10,0 | 160 x 3,9 | 5,85 |
2,4 / 5,0 / 6,0 / 7,0 / 10,0 | 180 x 4,4 | 7,44 |
2,4 / 3,0 / 5,0 / 6,0 / 7,0 / 8,0 / 10,0 | 200 x 4,9 | 9,15 |
Execution
End piece and flange are each attached to the tube container with 12 VA rivets. The flange is riveted from inside to outside. The cover is riveted with three VA hinges (for Ø 160 mm with two hinges) to the flange. The cover is locked as standard with two double-bit security rotary bolts. The locking latches grasp behind the aluminum locking bracket.
Scope of delivery
Tube complete with assembled/riveted lid (cover with flange) and end-fitting.
2 two-way key.
Accessories / Options
– Tube support
– Other locking systems (Spare parts)
– Door with flange on both sides
– Intermediate lengths are possible for all models (4% surcharge)

Compact hose tube container, triple
Length (m) | Diameter (mm) | Weight (kg / m) |
2,4 / 3,0 / 5,0 / 6,0 / 7,0 / 8,0 / 10,0 | 160 x 3,9 | 5,85 |
2,4 / 3,0 / 5,0 / 6,0 / 7,0 / 8,0 / 10,0 | 200 x 4,9 | 9,15 |
Execution
End piece and flange are each attached to the tube container with 9 VA rivets. The flange is riveted from inside to outside. The cover is riveted with a VA hinge to the flange. The cover is locked standard with a double-bit security rotary bolt. The locking latches grasp behind the aluminum locking bracket.
Scope of delivery
Tube complete with assembled/riveted lid (cover with flange) and end-fitting, buffer tank, 1 two-way key.
Accessories / Options
– Tube support
– Other locking sytsems (Spare parts)
– Door with flange on both sides
– Intermediate lengths are possible for all models (4% surcharge)
Mountings
Fastening clip - quick and safe
ROWEKO's specially developed VA-steel fastening clips not only hold the tubes safely in permanent use but also set visual accents. The mounting principle makes it quick and easy to fasten the hose tube container to the vehicle. The PE safety cap rules out the risk of any injuries. The fastening clips are coordinated to the ROWEKO hose tube container range and available in different designs. At least 4 fastening clips are required to mount a standard tube 5 m in length. An 8 m tube needs 6 fastening clips (at intervals of max. 1.5 m).
